CPU(Prosessor)
|
|
Support Intel® 6th., 7th., 8th. and 9th. generation Core™ i7/Core™ i5/Core™ i3 Series Processors in the LGA1151 package
|
|
Brikkesett
|
|
Intel® H110 Express Chipset
|
|
Minne
|
|
2 * 1.5V DDR3 DIMM sockets Suporting up to 16GB of system memory
|
|
Slotter
|
|
- 1 * PCI Express x16 slott
- 1 * PCI Express x1 slott
|
|
Lagring
|
|
- 4 * SATA 3GB/s kontakter, støtter opp til 4 x SATA 6GB/s enheter (3GB/s kan også brukes)
|
|
Interne I/O kontakter
|
|
- 1 * 24-pin ATX Power Connetor
- 1 * 8-pin ATX 12V Power Connetor
- 2 * USB connector support additional 4 USB 2.0 ports
- 1 * USB connector support additional 2 USB 3.0 ports
- 1 * Front panel audio connector
- 1 * System Panel connector
|
|
I/O kontakter på baksiden
|
|
- 1 * PS/2 Mus / Tastatur
- 1 * VGA
- 1 * HDMI
- 4 * USB 3.0
- 1 * RJ45(LAN) Port
- 1 * 3 Audio jacks
|
|
BIOS
|
|
|
|
LAN
|
|
Integrert Realtek 8111GN 10/100/1000MBs LAN
|
|
Audio
|
|
Integrert Realtek ALC887, støtter 5.1-kanalers audio
|
|
Format
|
|
- Micro ATX - 240*178 mm
|
