CPU(Prosessor)
|
|
Support Intel® 1. and 2. generation Core™ i7/Core™ i5/Core™ i3 E5 Series Processors in the LGA2011 package
|
|
Brikkesett
|
|
Intel® H61 Express Chipset
|
|
Minne
|
|
4 * 1.5V DDR3 DIMM sockets Suporting up to 64GB of system memory
Support for DDR3 1600/1333/1066/800MHz memory modules. ECC, Reg/ECC kan også brukes!
|
|
Slotter
|
|
- 1 * PCI Express x16 slott
- 2 * PCI Express x1 slotter
|
|
Lagring
|
|
- 4 * SATA 3GB/s kontakter, støtter opp til 4 x SATA 6GB/s enheter (3GB/s kan også brukes)
|
|
Interne I/O kontakter
|
|
- 1 * 24-pin ATX Power Connetor
- 1 * 8-pin ATX 12V Power Connetor
- 2 * USB connector support additional 4 USB ports
- 1 * Front panel audio connector
- 1 * System Panel connector
|
|
I/O kontakter på baksiden
|
|
- 1 * PS/2 Mus / Tastatur
- 2 * USB 3.0
- 6 * USB 2.0 / 1.1
- 1 * RJ45(LAN) Port
- 1 * 3 Audio jacks
|
|
BIOS
|
|
|
|
LAN
|
|
Integrert Realtek 8111F 10/100/1000MBs LAN
|
|
Audio
|
|
Integrert Realtek ALC662, støtter 5.1-kanalers audio
|
|
Format
|
|
- Micro ATX - 237*250 mm
|
